bj-jit

Ever since learning to create an interpreter, I had been increasingly interested in going deepr. I wanted to learn compilation, optimization and just in time compilation. I knew this was going to be a very heavy set of content to go in blindly, so I knew I wanted to implement all of this on a smaller scale to start. BrainFuck, being a very very simple turing-complete language, was the perfect target for this exactly

bf-jit provides every step of this process as independent runtime targets that can be swapped out: a basic interpreter, an assembler, an ELF64 compiler and finally a Just In Time x86-64 compiler

Architecture Overview

The bf-jit system follows a modular architecture with a unified frontend that can target multiple backends:

Brainfuck Source -> Tokenizer -> Intermediate Representation
                                          |
                                          v
              +----------------+----------------+-----------------+
              |                |                |                 |
         Interpreter      Assembler        ELF Compiler      JIT Compiler
              |                |                |                 |
         treewalk        x86 assembly    Standalone binary   Native execution


Tokenizer and Parser

The system begins with a generic tokenizer that processes Brainfuck source code into tokens representing the eight Brainfuck commands: >, <, +, -, ., ,, [, and ]. Repeated operations of the same type are compressed into a single token with repeated metadata (aside from loop boundaries)

1. Interpreter

The interpreter is the simplest backend, executing Brainfuck commands directly:

• Maintains a 30,000-byte tape buffer
• Uses a pc pointer and data pointer
• Directly runs through a loop moving the pc

2. Assembler

The assembler backend generates x86-64 assembly code from the Brainfuck IR:

• Maps Brainfuck operations to equivalent x86-64 instructions
• Creates a 30,000 byte buffer tape in the bss section
• Uses labels to manage looping
• Outputs a .s file that can be compiled with a tool like clang

3. ELF64 Compiler

The most complex static compilation backend generates complete ELF64 executables:

• Manually constructs ELF headers, program headers, and section headers from a raw byte buffer
• Generates proper entry point and 30k byte buffer in bss
• Similar to the assembler, maps each instruction to the x86-64 instruction(s). Only this time it's raw machine code.
• To deal with loops, keeps a count of how many bytes each instruction is and does a relatie jump by that byte count in between
• Outputs a raw executable file

4. JIT Compiler

The JIT compiler provides the speed of the compiler at the convenience level of the interpreter:

• Allocates executable memory pages using mmap with PROT_EXEC
• Maps 30k byte buffer in program space before executing the mmaped and just passes a pointer to it
• Emits raw x86-64 machine code directly to memory in the same way the compiler does
• On finish, treats the memory like a function pointer and executes it directly
